DESIGN-CLIP profiles are uniquely designed for floating flooring systems. It’s two-part profile system with a smooth surface allows for a (6mm) 1/4” expansion. Professional installers can install the profile quickly and easily, due to the user-friendly click technology and extremely solid click connection. Design-Clip is a suitable transition for resilient floor coverings and carpets of different heights, as well as same-level transitions and edge trim.
MONO-CLIP profiles are especially designed for all hard flooring options from (7-22mm) 9/32-7/8”. A two-part profile system with three different base options allows for a (13mm) 1/2” expansion. Paired with new friction-locked technology, it makes for a more convenient, faster and safer installation. The smooth surface and slender design with no visible screws are sure to impress.
.jpg)
CLIP SYSTEM GUIDE
The Küberit clip system covers transitions and floor edges on laminate and other floating floors without a screw in sight. Both profiles are two-part systems: a base rail is fixed first, the visible cover clips onto it. The choice between them comes down to what you are installing and how much movement the floor needs.
Floor coverings
Design-Clip: resilient flooring such as click vinyl, 4–7 mm (5/32–9/32"), and carpet · Mono-Clip: laminate, engineered wood and other hard flooring from 7–22 mm (9/32–7/8")
Expansion allowed
Design-Clip: 6 mm (1/4") · Mono-Clip: 13 mm (1/2")
Connection
Design-Clip: click technology · Mono-Clip: friction-locked, three base options
Profile shapes
Both systems: reducer (TP1), edge trim (TP2) and same-level transition (TP3)
Visible fixings
None on either system
A floating floor, such as laminate or click vinyl, is not bonded to the subfloor. It expands and contracts as a whole, which is why it is laid with a gap at every edge and at every transition. A clip profile has to bridge that gap and still leave the floor free to move. That is what the two-part construction does: the Design-Clip allows 6 mm (1/4") of expansion, the Mono-Clip 13 mm (1/2"). Fixing a rigid profile straight through a floating floor removes that allowance — which is the reason the clip system exists.
The Mono-Clip KC-M is the clip-on laminate transition strip for laminate, engineered wood and other hard flooring from 9/32" to 7/8" (7–22 mm). Bases and tops are ordered separately: the KC-M-120, KC-M-170 and KC-M-220 bases in natural aluminum match floor heights of 7–12, 12–17 and 17–22 mm, and each base takes one of three tops. TP1 is a reducer for laminate to carpet or to any lower floor and is ADA compliant up to 9 mm. TP2 is an edge trim that finishes the open edge of the floor like an end cap. TP3 is a T-shaped transition, the metal counterpart of a T-molding, for floors of the same height, for example between two rooms or from laminate to tile. The Design-Clip KC-D follows the same principle for resilient flooring and carpet from 5/32" to 15/32" (4–12 mm): one countersunk base, supplied with Torx screws, takes a TP1 reducer, a TP2 edge trim or a TP3 transition, and KC-D-TP1 is ADA compliant.
The visible tops come in anodized aluminum in silver, sand or bronze and in seven wood decors (W1–W7) that blend with laminate and wood floors; the Mono-Clip bases are natural aluminum. The wood decors have an AC3 abrasion-resistant coating, with AC5 for heavy commercial use on request. Custom lengths, colors and finishes, including powder coating in almost any RAL color, are available on request with minimum quantities. The standard length is 2.50 meters (approximately 8' 2-1/2"). For transitions on floors that are bonded rather than floating, see the KT-Transition range.
